PANORAMIC

Full color gamut shaking head beam laser

Tri-phosphor RGB laser 60W luminous power

Sky Survey Beam Light

High-strength aviation magnesium alloy, IP65

0.35° angle, 350000lux@20mt

0~100%, smooth dimming without flicker

Independent strobe, adjustable from 0.5 to 20 times/second

TECHNICAL DATA

Verse is a RGB Full color gamut shaking head beam laser Outdoor.
Strong light effect and penetration, long distance, high brightness, and strong photoplasticity.
Strong compatibility – Intelligent operating systems can be perfectly compatible with market control systems. High stability – patented heat dissipation technology combined with electronic temperature control ensures longevity and stability.
Energy saving and environmental protection – high photoelectric conversion efficiency, 1 watt can convert 300lm brightness, and optical design allows for higher optical conductivity and lower energy consumption.

A great choice for entertainment and big events.

Tri-phosphor RGB laser source 60W luminous power
Color T°. 7500K (adjustable)

0.35° angle
Illumination 350000lux@20mt
Adjustment Horizontal 540° Vertical 270°
Optcial Lens light outlet 160mm

Sky Survey Beam Light
Full color gamut shaking head beam laser
0~100%, smooth dimming without
flicker, Independent strobe,
adjustable from 0.5 to 20 times/
second , Electric linear focusing

DMX512, self-propelled

Input voltage:100V~240V AC 50/60Hz
Power 400W @25℃

Work noise 56d@25℃, at a distance of 1 meter
Gamut coverage NTSC150%、BT.2020
High-strength aviation magnesium alloy
High temperature resistance fire and aging
Wear resistance
Light weight and fall resistance

5 pin dmx Powercontrue in/out

Installation Formal, inverted, and side mounted
Housing color Black
T°Operativity -20℃~40℃
Cooling Cooling: Heat sink, fan-free
IP:65
Dimension: 239×375×651mm
Net weight:22KG
